PLN6 xPole Miniature Circuit Breaker

The PLN6 miniature circuit breaker (MCB) is a protective device that’s equipped with both a thermal and an electromagnetic release. The former responds in the event of an overload, while the latter offers protection against short circuits. The 1+N-pole MCB is only 1 HP wide and is available with rated currents from 2 A to 40 A. The switching capacity is 6 kA.

The circuit breaker, which is available with tripping characteristics B and C, is equipped with a red-green contact-position indicator for indicating the device state: green means that the contacts are open, and red that they are closed.

Core Features

• Premium 1+N pole miniature circuit breaker for residential and non-residential buildings
• Highly compact – only 1 HP wide
• Current limiting class (formerly selectivity class) 3
• Back-up fuse with high selectivity, thanks to low let-through energy
• Contact position indicator red – green
• Rated currents up to 40 A
• Tripping characteristics B, C
• Rated switching capacity 6 kA according to IEC/EN 60898-1
• Complies with the insulation coordination requirements (= distance between the contacts ≥ 4 mm)
• Busbar compatible
• Lift/claw double terminals at top and bottom
• For mounting on busbar at top or bottom, as required
• Guide for secure terminal connection
• Comprehensive range of accessories, which can also be retrofitted
• Switch-grip in rated current color

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

SCS200 – Intelligent Power Management

Intelligent and complex systems as well as the electrification of loads currently play a decisive role in the development of on-board electrical systems.

The SCS200 is the right answer to these requirements. It is an intelligent power distribution system, enabling decentralised control and monitoring of loads via CAN bus. The design features a PCB-based power distribution in a compact IP66/67 enclosure.

The SCS200 modules are plug & play solutions which help reduce wiring time and space requirements. Its comprehensive diagnosis capability (integral load protection, load current and voltage measuring, output status) and its integral CAN connection enable predictive maintenance and implemented load management.

Typical Applications:

• Agricultural machinery, construction machinery, special vehicles, trucks and buses
• Decentralised power distribution downstream the ECU
• Vehicle modernisation and easy system extension through standardised CAN components

Benefits

• Predictive maintenance and load management through comprehensive diagnostic functions (current, voltage, status)
• Facilitated wiring through plug & play solution with CAN connection
• Space-saving, flexible installation through compact IP66/67 housing
• Increased safety through integral electronic load protection
