UHS Fuse 50-100A, 32/50VDC, 8.4 x 9.4mm

The Schurter UHS is a compact, fast-acting SMT/PCB fuse designed for Separated Extra Low Voltage (SELV) applications where high breaking capacity and fast tripping are required.

Description:
This fuse was specially developed for SELV applications with
high rated currents for highest breaking capacity demands.
Thanks to its design, the fuses tripping time minimizes excessive
temperature dissipation at 2x rated current.

Features:

• High breaking capacity up to 2000A
• Safe tripping in 10s at twice the rated current
• High range of operating temperature
• Small component height of 4.7mm

Applications:

• Automotive
• Telecom equipment
• Datacenter appliances
• Power tools

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

DG11 IEC Appliance Inlet C14 or C18 with Circuit Breaker TA35 2-pole with Thermal or Thermal-Magnetic Release

The Schurter DG11 is a power entry module designed
for IEC appliance inlets (C14 or C18) combined with
a 2‑pole TA35 circuit breaker offering thermal or
thermal‑magnetic release. It is intended for use in
equipment protected to IEC/UL 62368‑1 and suitable
for protection class I or II devices.

It provides a reliable alternative to traditional
fuse-protected power entries by featuring resettable
overcurrent protection, reducing components, and
removing the need for a separate fuse.

Description:

• Panel mount: Screw-on version from front or rear side, snap-in version front side: Appliance Inlet, protection class I or II, Circuit breaker type TA35, 2-pole, with thermal or thermal-magnetic release
• Pre-wired coupling
• V-Lock notch standard
• Quick connect terminal 6.3 x 0.8 mm

Key Features:

• With sealing: IP54 under load, IP67 towards housing
• Thermal or thermal-magnetic circuit breaker; thermal-magnetic release fast acting or with time lag
• Recessed rocker prevents accidental manipulation
• Various mounting options

Characteristics:

• Connector and circuit breaker are prewired
• Circuit Breaker thermal or thermal-magnetic, non-illuminated or illuminated
• Suitable for use in equipment according to IEC/UL 62368-1

Applications:

• Medical Equipment
• Industrial Automation & Control
• IT & Telecommunications
• Audio, Video, & Lighting
