PLN4 xPole Miniature Circuit Breaker

The PLN4 miniature circuit breaker (MCB) is a protective
device that’s equipped with both a thermal and an
electromagnetic release. The former responds in the event
of an overload, while the latter offers protection against
short circuits.

The 1+N-pole MCB is only 1 HP wide and is
available with rated currents from 2 A to 40 A. The switching
capacity is 4.5 kA. The circuit breaker, which is available with
tripping characteristics B and C, is equipped with a red-green
contact-position indicator for indicating the device state.

Core Features

• Premium 1+N pole miniature circuit breaker for residential and non-residential buildings
• Highly compact – only 1 HP wide
• Current limiting class (formerly selectivity class) 3
• Back-up fuse with high selectivity, thanks to low let-through energy
• Contact position indicator red – green
• Rated currents up to 40 A
• Tripping characteristics B, C
• Rated switching capacity 4.5 kA according to IEC/EN 60898-1
• Complies with the insulation coordination requirements (= distance between the contacts ≥ 4 mm)
• Busbar compatible
• Lift/claw double terminals at top and bottom
• For mounting on busbar at top or bottom, as required
• Guide for secure terminal connection
• Comprehensive range of accessories, which can also be retrofitted
• Switch-grip in rated current color

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

E-T-A High Performance Circuit Breakers

Typical Applications

High performance circuit breakers are ideally suited to protect against overcurrent and short circuit for use in aircraft and vehicles and other specialised equipment where safety is paramount. Battery isolation switches are ideally suited for installation in the main battery systems of heavy duty vehicles including tankers, boats, off-road plant and other battery-powered equipment.

Technology

High performance circuit breakers feature thermal or thermal-magnetic trip and an extremely high rupture capacity. Battery isolation switches are also based on a thermal-magnetic trip mechanism. The thermal part of the circuit breaker provides delayed protection in the event of overload, the magnetic part disconnects the faulty circuit in the event of overload or short circuit within milliseconds.

Customized High Performance Circuit Breakers such as SG, AP or CBM types are available on request. All products of this group provide genuine physical contact isolation.
