4750 Strip Block for Snap-in Mounting with up to 7 IEC Appliance Outlets F

The Schurter 4750 Series is a configurable, snap-in mounting strip block designed for high-density intelligent Power Distribution Units (PDUs) and data center equipment. It compactly houses 2 to 7 IEC Appliance Outlets (Type F) and eliminates the need for external LEDs by integrating optional light pipes for status indication.

Description:

• Panel mount
• Snap-in version front side (1.2 / 1.5 / 1.7 mm)
• Configurable Strip block from 2 up to 7 outlets type F
• Cord retention for cordsets with V-Lock, Twylock or P-Lock
• Pre-assembled Light Pipe for status indication
• Solder / PCB / QC (4.8 / 6.3 x 0.8) mm

Key Features:

• Configurable Bus bar (L, N, PE)
• Optionally with or without light pipes on L or N side
• Color coding in black (grey and white upon request)
• Solder / PCB / QC (4.8 / 6.3 x 0.8 mm)

Characteristics:

• Compact solution for intelligent PDU applications
• Suitable for use in equipment according to IEC/UL 62368-1

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

77 Series: Modular Solid State Relays (SSR) 5-15-30A

The 77 Series is made up of modular and “hocky puck” style solid state relays

Functions & Features (according to Type):

• Input AC or DC
• 230V AC or 400V AC output
• Rated voltage range (19…305)V AC or (48…480)V AC
• Zero-crossing and random switch-on versions
• Suitable for lamp loads
• 17.5 and 22.5 mm housing

Features (“hockey puck”):

• Input AC or DC
• 230 V AC or 400 V AC output
• Switching voltage range (19…305) V AC or (48…480) V AC
• Suggested applications: heater control
• Mounting to heatsink with screws
• Zero-crossing version

Applications:

• Drying kilns
• Heating and cooling
• Lighting control in corridors (for hotels, offices and hospitals)
• Bottling plant
• Labelling machines
• Packaging machines
