Revos POWER contact inserts and adapter units are designed for currents up to 100A, and are also available in mixed amperage contact versions – perfectly protected within the revos BASIC housing line.

Revos POWER is used in wind power plants, construction machinery, utility vehicles, machine building, control systems, and larger drives.

revos POWER combines power and control contacts in a single connector.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

DKCV-1 Current-Compensated Chokes for Vertical PCB Mounting

• Very high inductance
• Compact design with a small footprint
• Open structure for optimized cooling
• Optional customer-specific versions

Schurter is launching a new, vertically mountable choke family for PCBs with very high inductances. The DKCV-1 current-compensated chokes are designed for currents from 0.5 to 10 A. Thanks to their nanocrystalline cores, the new chokes have very high inductances with particularly compact dimensions.

Powerful applications in the energy sector are becoming increasingly compact. This compact design combined with high energy efficiency leads to an increase in electromagnetic interference in modern electronic devices. Powerful filter elements are required to suppress this interference. Due to the compact dimensions, the integration of the filter elements on printed circuit boards is an ideal solution. The new DKCV-1 choke series is particularly suitable for applications that require high attenuation.

High Performance in a Compact Design
The nanocrystalline cores enable very high currents with extremely compact dimensions. Thanks to the vertical choke arrangement, they also require very little space on the PCB. All variants of the DKCV-1 family have the same footprint on the PCB.

Applications
The new chokes are ideal for demanding applications that require high inductance with compact dimensions. These include switching power supplies, industrial, medical, laboratory and test equipment. The chokes are suitable for currents up to 10 A and voltages up to 300 VAC or 450 VDC and have ENEC,
cUR and UR approvals. For higher power applications, the DKIV-1 series of chokes is available with rated currents up to 50A.
