MSM II-Switch with common anode control of the RGB LED

• Optimised for industrial control architectures
• Usual SCHURTER Metal Line quality
• Protection class IP67

The well-established MSM II mechanical switch family is growing. With the MSM II (Common Anode), Schurter is introducing a variant that uses a common anode to control the RGB LED illumination. This combines the familiar robust mechanics with visualization technology for clear feedback, easy integration, and maximum reliability in control and operating solutions.

RGB LEDs can be controlled either via a common anode (+) or a common cathode (–). While with common cathode all negative poles are connected together and the colors are controlled individually via the positive pole, the common anode variant does the opposite: all positive poles are connected, and the color channels are switched separately to ground.

The MSM II (common anode) offers maximum compatibility with modern driver ICs, PLC outputs, and microcontrollers, which are predominantly designed for common anode control. This facilitates integration thanks to a simple signal structure and reduced wiring requirements.

The combination of tactile precision, IP67 protection, robust design, and flexible RGB signaling makes the MSM II switch ideal for a wide range of applications, particularly in industrial control units such as control panels, production facilities, building automation, and access solutions.

The combination of tactile precision, IP67 protection, robust design, and flexible RGB signaling makes the MSM II switch ideal for a wide range of applications, particularly in industrial control units such as control panels, production facilities, building automation, and access solutions.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Solid state remote power controllers are used for reliable protection, switching and monitoring of DC 24 V circuits and loads in the steel industry, automation and chemical industry.

SSRPCs are suitable for reliable switching, protecting and monitoring of resistive and inductive loads. The offer a range of functions including overload and short circuit protection as well as wire break detection, they help to avoid consequential damage or system downtimes, thereby reducing costs.

Applications:

• Factory Automation & Machinery: Used for switching and protecting DC 24V circuits, particularly in steel, chemical production, and machinery control, adhering to safety standards like EN 60204.
• Commercial Vehicles & Transportation: Ideal for buses, trucks, construction machinery, and agricultural vehicles to replace mechanical relays for increased longevity.
• Industrial Control & Process Control: Used for controlling solenoids, magnetic brakes, and clutches.
• Power Distribution: Employed in intelligent power distribution systems (e.g., ControlPlex®).
• Medical & Equipment Technology: Utilized in professional tools and commercial kitchen appliances.

Benefits:

• Diagnostic Capabilities: Features built-in monitoring for wire breaks, overload, and short circuits.
• Reduced Downtime: Eliminates mechanical wear, improving system reliability.
• Reduced Wiring: Minimizes wiring efforts in complex control cabinets.
