Wieland Official Distributor

Industrial single phase Switch Mode power supply 24 V DC, 480 W output, Output adjustable between 24-28 V, Double stage with active PFC (Power Factor Correction).

Function & Features:

• High efficiency (up to 92%)
• Low stand-by power consumption
• Active PFC
• DC output voltage adjustable
• Short circuit protection with hiccup auto-recovery
• Thermal protection with auto shoutdown
• High peak current up to 30%
• Boost current up to 30% for 3 s (depending on version)

• Overvoltage protection: Varistor
• Compliant with IEC/EN 62368-1, UL 61010
• Parallel working for increased load current (with
  external diode) or redundancy
• 35 mm rail (EN 60715) mount

Applications:

• Building Automation
• Elevators and Lifts
• Automation for Blinds and Shutters
• Hoists and Cranes
• Panels for Electrical Distribution
• Control Panels for Pumps

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

EKO: High-Performance HV Fuses for Industrial and Energy Applications

• Rated voltage: 1000 VDC (1250 VAC available for
  selected series)
• Rated currents: 50 – 1100 A
• Breaking capacity: 50 kA DC (100 kA AC for
  selected series)
• Characteristic HV Fuse Mounting Flush End,
  DIN-Rail, US Style Bolted Tag, Bolt-on

The EKO series is engineered for demanding high-voltage environments, offering protection up to 1000 VDC (and 1250 VAC for selected models) and current ratings from 50 to 1100 A. With a breaking capacity of up to 50 kA DC, these square-body fuses deliver safety and reliability.

Designed for robust performance, the EKO series withstands mechanical vibration, shock, chemical exposure, and extreme temperatures from -40 °C to +125 °C. Its ceramic housing and tin-plated copper alloy terminals ensure durability and stable electrical characteristics even under harsh conditions.

Choose from Flush End, DIN-Rail, US Style Bolted Tag or Bolt-on to simplify integration into diverse systems. Optional indicators and microswitches enable easy status monitoring.

The EKO series meets IEC, UL, and GB/T standards and complies with CE, RoHS, and REACH directives, ensuring global acceptance and peace of mind.

Schurter EKO fuses combine high performance with proven safety—your trusted choice for modern high-voltage protection.

Variations

• EKO11: 160–400 A / 1000 VDC / 1250 VAC / Flush End / DIN-Rail
• EKO12: 125–630 A / 1000 VDC / Flush End / US Style Bolted Tag
• EKO13: 250–800 A / 1000 VDC / 1250 VAC / Flush End / DIN-Rail
• EKO14: 315–1100 A / 1000 VDC / 1250 VAC / Flush End / DIN-Rail
• EKO81: 50–400 A / 500 VDC / Bolt-on
  Optional indicator and microswitch for EKO11–EKO14
