Crydom’s advanced DC Switching Technology is now conveniently packaged in a High Power “H” Bridge configuration with optional Soft Start, Soft Stop & Brake features for use in DC Load Reversing applications up to 60 amps at 48 VDC.

Crydom introduces the DP Series of High Power “H” Bridge configuration DC output Solid State Contactors, including control features for Soft Start, Soft Stop, and Brake functions. Rated for General Use at 20, 40 or 60 amps and Motor Controller rated for 15 FLA from 1 to 48 VDC in a 40 °C ambient temperature, the DP Series accepts logic supply and Input Controls of either 4.5 to 15 VDC or 18 to 32 VDC. Optional Soft Start/Soft Stop functions utilizing internal PWM are available with 0.2, 0.5 or 1.0 second ramps. An optional Brake function (not available with Soft Stop) is available with 0.2, 0.5, 0.8 seconds or continuous hold.

The DP Series Solid State DC Reversers are an all-solid-state design with 2.5 Kv Optical Isolation and incorporate low dissipation power FETs for fast and efficient Load control. Housed in an industry standard 75 x 105 mm Panel Mount package, Power and Load terminations are via screw terminal post, while Input Control is through an industry standard 4 conductor connector. DP Series Reversers are CE certified, RoHS compliant, UL/cUL recognized for both General Purpose and Motor Controller applications.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Crydom’s World Class Solid State Relay Technology is now available to Electromechanical Relay users in the industry standard 12 x 29 mm plug-in package with ratings of either 3 or 5 amps up to 280 VAC or 80 VDC.

Crydom’s new “LifePlus ED series” of AC and DC output pluggable Solid State Relays offer Electromechanical Relay users the opportunity to directly replace traditional 12 x 29 mm EMRs with Crydom’s proven Solid State Relay Technology. Solid State Relays offer substantial performance advantages over traditional EMR switching solutions in many applications including significantly greater life expectancy (>100 million operations), contactless high speed switching eliminating contact bounce and resulting electrical noise, precise logic compatible control inputs, acoustically silent operation and high vibration resistance, among many others.

Available in a SPST N.O. configuration, the “LifePlus ED series” offers output ratings of either 3 or 5 amps rms at 24 to 280 VAC, or 5 amps dc at 1 to 48 or 1 to 80 VDC, all at 40 °C ambient temperature. AC outputs incorporate Crydom’s proven Back-to-Back SCR technology while DC outputs utilize high efficiency FETs, both technologies resulting in the lowest possible on-state power dissipation and high surge current ratings which make the “Crydom LifePlus” an excellent choice for applications such as small Motors, Solenoids, Heaters and Lamps. Optically isolated control inputs available include 3 to 15 VDC, 18 to 32 VDC, 48 to 72 VDC, 18 to 36 VAC and 90 to 140 VAC.

Cydom’s “LifePlus ED series” relays are UL 508 recognized for both general purpose and motor control applications and compliant to IEC 62314 LC-A resistive and LC-B inductive application requirements. They are also CE certified to the IEC Low Voltage Directive and compliant to the IEC EMC Directive. The “LifePlus ED series” relays are available in the industry standard 12 x 29 mm plug-in relay package and fit standard DIN rail and PCB mountable sockets, allowing direct replacement of SPST N.O. EMRs in most applications. Featuring all solid state construction, “LifePlus ED series” SSRs provide an excellent improvement in performance over traditional EMRs .

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The expanded DRA Series now includes compact DIN Rail Mounted 3 Phase AC Solid State Contactors, 3 Phase AC Solid State Motor Reversing Contactors, and DC Solid State Motor Reversing Contactors!

Crydom introduces its expanded offer of DRA Series compact DIN Rail Mounted Solid State Contactors. Complementing existing single channel and four channel AC and DC output DRA Series, the new models include 3 phase UL approved AC output ratings of either 1 or 2 horse power at 480 VAC in both contactor and motor reversing configurations, and UL approved DC output ratings of ¼ horse power at 90 or 180 VDC. IEC 60947 ratings are available as well for both AC and DC output DRA Series.

DRA Series 3 Phase Contactors feature an SCR output all solid state design with 4000 VAC optical isolation, AC or logic compatible DC control inputs, both with input status indicator, UL approved motor and AC output resistive load ratings of either 2.4 or 4.2 amps per phase from 48 to 510 VAC. Motor reversing models also include a control interlock feature that allows only off, forward and reverse operation.

DRA Series DC Motor Reversing models feature a FET output all solid state design with 2500 VAC optical isolation, logic compatible DC control inputs with input status indicator, and UL approved motor and DC output resistive load ratings of either 6 A @ 180 V and 12 A @ 90 V.

Designed for easy mounting to standard 35 mm DIN Rail, the new DRA Series of 3 Phase AC and DC output Solid State Contactors and Motor Reversers are available in a variety of input and output ratings.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Joining Crydom’s broad line of Panel Mounted Solid State Relays, the new “EL” series offers AC & DC Outputs in a compact 21 mm wide package featuring imbedded quick connect terminals.

.

Crydom’s new “EL” series  of Compact Solid State Relays include models with output ratings up to 20 Arms from 24 to 280 VAC or 10 Adc from 3 to 100 VDC with optional external heat sink.  Logic compatible control input versions include 5, 12 or 24 VDC.  Output termination is via 0.25” (6.35 mm) quick connect terminals, while input terminals are 0.187” (4.75 mm) quick connects.

Featuring 4kV all solid state optical isolation, the Triac output AC versions are available with either zero voltage turn-on for resistive load
applications or random turn-on for inductive load applications, while  DC output versions feature low RDS on resistance FETs suitable for most DC resistive or inductive loads. “EL” series SSRs are RoHS & China RoHS compliant, CE certified, UL and cUL recognized.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Employing Crydom’s proven DC solid state switching technology, the new LVD series provides a simple means of disconnecting batteries from their loads to prevent operational problems or damage resulting from deep cycle discharge.

.

Crydom’s new "LVD" series of DC output Low Voltage Disconnect Solid State Switches is designed to disconnect 12 or 24 volt battery systems from their loads when the battery voltage falls below a pre-selected DC voltage. The LVD will also automatically reconnect the load circuit once the battery voltage returns to a normal value after charging. The LVD series is offered in a rugged industry standard encapsulated panel mount package with screw terminals.

The Crydom LVD series requires no operator interface to interrupt or reconnect the battery circuit. Featuring all solid state construction with a low Rds on resistance FET outputs rated at 40, 60, 80 or 100 amps maximum, the LVD series is available with 6 different threshold voltages to choose from. The LVD series is RoHS & China RoHS compliant.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Crydom’s proprietary thermal management technology utilized in the new “SeriesOne DR” line offers 6 & 12 amp single and 6 amp dual channel output ratings in compact 11 & 18mm wide DIN Rail mounted SSRs.

Crydom’s new “SeriesOne DR” family of AC and DC output DIN Rail mounted Solid State Relays are intended for use in heating, lighting and motion control applications where DIN Rail mounting is preferred and higher output power ratings are required. Featuring a unique proprietary thermal management design with no exposed hot metal surfaces for safety, the SeriesOne DR family includes AC output ratings at 40°C ambient for single channel models of either 6 or 12 amps, and dual AC output models with 6 amps per channel, each rated at either 12 to 280 vac or 24 to 600 vac. DC output model ratings at 40°C ambient include single channel versions rated at either 6 or 12 amps and 1 to 60 vdc or 1 to 100 vdc.

The SeriesOne DR features 4 to 32 vdc, 90 to 140 vac, 208 to 265 vac or 18 to 36 vac inputs and includes an LED input status indicator. The SeriesOne DR 6 amp single channel versions are 11 mm wide while the 12 amp single channel and 6 amp dual channel SSRs are each 18 mm, all mounting on the industry standard 35 mm DIN Rail.

AC output versions offer 3.75kV all solid state optical isolation with SCR outputs and are available in either zero voltage turn-on for resistive load applications, or random turn-on for inductive load applications. DC outputs offer 2.5 kV all solid state optical isolation with FET output for either resistive or inductive load applications. SeriesOne DR SSRs are RoHS & China RoHS compliant, CE certified, UL and cUL recognized including both General Purpose and Motor Controller ratings.

.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Complementing Crydom’s extensive offer of Heavy Duty High Power Solid State Relays, the new “CL” series is optimized for lighter duty applications in heating, lighting and motion control.

Crydom’s new CL series of AC output Solid State Relays is intended for general purpose use in heating, lighting and motion control applications where panel mounting is desirable but traditional heavy duty SSRs are not required. Rated at either 5 or 10 amps output from 24 to 280 VAC, the CL series features either 3 to 32 VDC or 90 to 250 VAC inputs and includes an LED input status indicator. The CL series is offered in the industry standard panel mount SSR package and is available in either IP00 or IP20 touch safe screw terminal configurations.

Featuring 4kV all solid state optical isolation with Triac output, the CL series is available with either zero voltage turn-on for resistive load applications or random turn-on for inductive load applications. An output RC snubber network is also included for applications with highly inductive loads or noisy power lines. The CL series is RoHS & China RoHS compliant, CE certified, UL and cUL recognized.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The Crydom CTR Series of DIN Rail mounted Three-Phase AC Output Solid State Contactor Relays includes models with 25 amps per channel Output at 600 VAC, AC or DC Control Inputs, IP20 Touch Safe Design, UL approval and CE certification.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, announces the introduction of the CTR Series of 90 mm wide three-phase DIN Rail mounted AC output SSRs.

The new Crydom CTR series offers UL approved AC output ratings of 25 amps per channel at 600 VAC, AC or DC input control, zero voltage or random turn on, and IP20 touch safe construction with integral heat sink. Mounting to industry standard 35 mm DIN rail, the CTR Series also includes compliance to the IEC CISPR 11 Class A emissions requirements, IEC61000-4-2 through -6, level 3, transient susceptibility standards, RoHS compliance, and CE Certification to the Low Voltage Directive.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The CN series features 5 mm wide pluggable/PCB mountable single-in-line AC and DC output SSRs, Single channel DRS series sockets for CN series SSRs, and DIN rail mounted CN series SSR/Socket Assemblies.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, introduces a new line of pluggable/solderable single in-line Solid State Relays, DIN rail mounted sockets and ready to use SSR/Socket Assemblies.  The 5 mm wide CN series SSRs meet industry standard pin out configurations for both Solid State and Electromechanical relays and are designed to be plugged into Crydom DRSCN series sockets or soldered into printed circuit boards. Featuring all solid state optically coupled designs, CN series models are available with either a 240/2 amp AC output, 24/3.5 amp DC output, or 48/0.1 amp DC output. Available input configurations include 2.5 to 12 VDC, 15 to 30 VDC and 38 to 72 VDC.

DRSCN series DIN rail mounted sockets include input status LED indicator and are available for 5 to 12 or 15 to 30 VDC control inputs, and 60 to 120 or 60 to 250 VAC/VDC control inputs. The 6.2 mm wide DRSCN sockets are designed to accept industry standard 5 mm wide SSRs or EM relays and snaps onto standard 35 mm DIN rail. SSRs are easily plugged into the sockets and removed via a convenient latch mechanism. Available Marker Strips for the sockets are also offered to allow easy circuit function identification for each socket.

Combining the CN relays and DRSCN sockets, Crydom also offers ready to use SSR/Socket assemblies. The DRA-CN series of assemblies offer all of the features and benefits of both the CN SSRs and DRSCN sockets, but in a ready to use configuration.

The Crydom CN series of SSRs, Sockets and Assemblies offer a fast, simple and compact means of adding control functions to any application.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The Crydom 53 series of Panel Mounted 3Phase AC output Solid State Relays
now includes new IP20 touch safe models and 3Phase motor reversing models,
all meeting IEC emissions & transient susceptibility requirements.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, announces the addition of 36 new models to its successful 53 Series of Panel mounted AC output 3Phase SSR Contactors. The expanded Crydom 53 Series offer now includes models featuring IP20 touch safe covers with load current ratings of either 25 or 50 amps per channel at 530 VAC. Designed for harsh environments and available with either AC or DC input control voltages, the new 3Phase models also feature IEC emissions compliance to CISPR 11 Class A, and EMC immunity per IEC 61000-4-2 through -6, level 3.

The 53 Series offer from Crydom now also includes 2 new 3Phase Solid State motor reversing Relays rated at either 25 or 50 amps per channel. The reversing models include the same IP20 touch safe design, Class A emissions and level 3 noise immunity as the new 3 phase SSR contactor models. Available with 3 to 32 VDC input control, Reversing models include a safety control interlock circuit which prevents simultaneous forward and reversing commands.

All new Crydom 53 Series SSR Contactors and Motor Reversing SSRs are UL & cUL recognized, TUV approved and CE compliant to Low Voltage Directive.
