The diversified appliance couplers from SCHURTER are successfully in use throughout the world. This product portfolio has been widened through the series 5001 of panel mounting appliance outlet, specially developed for printed circuit board mounting. Mounting onto PCB’s provides the user with high cost effectiveness.

The series 5001 is available in protection classes I (3 pole) and II (2 pole). The earthing contact (arrangement in protection class I) is provided with an additional terminal for connecting the appliances chassis directly at the power input.

The 5001 housing is made from polyamide PA6 / UL 94V-0. Current carrying parts are made from a copper alloy. The pins are nickel plated and the connections tinned. In the standard arrangement of the 5001, 4 fixing holes are available for mounting. Fixture onto a panel or PCB takes place with screws or rivets.

A special arrangement with snap rivets is also available for PCB mounting.

The 5001 appliance complies with standards IEC60320 / EN 60320 / VDE 0625.

Approvals:
- ENEC 05: 10A / 250 Vac
- cCSAus: 15A / 250 Vac

The 5001 appliance outlet is used for mains extensions and is to be found in applications such as power distributors, household devices, entertainment electronics, office communications, medical technology, industrial electronics and automation.

Technical Features:
- Panel mounting appliance outlets IEC 60320 type F and H
- Rated current range: ENEC 10 A, cCSAus 15 A at 250 VAC

.

Home Page: https://www.epreston.co.uk/epblog/

V-Lock Cord Retaining System

This V-Lock system by Schurter is an attractive and simple solution to prevent an unintentional unplugging. Various different connectors, Power Entry Modules and several country-specific power cables are available with this option.

.

The V-Lock locking system can be used for 10A and 16A power inlets and connectors according to IEC 60320. This system works in such a way that there is a pin in the socket, interlocking with a notch in the plug and thus prevents an unintentional pullout of the power cable. The advantage of this system is that there is no need for a specific socket system or retaining device that has to be adapted and built-in.

The locking is released by pressing on the releasing lever. This lever is easily detected by its bright yellow colour and thus distinguishes this system from existing power cable connections. The extraction force is a minimum of 200 N. Typical applications are in medical appliances,
analysis and laboratory instruments, Telecom and IT- devices, power distribution or radio and TV-studios.

.

USP's: - prevents unintentional disconnection
- increased safety and reliablility
- most cost effective cord retaining solution on market
- attractive design
- easy to use

The following connector types can be manufactured with the V-Lock option in series:
6010, 6061, GSP1, GSP2, DF11, 6600-3, 6600-4, 6610, 4797

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Schurter extends its ECO filtered power entry module for DC applications, series 5003, with a newly added PCB mount version, and version with flexible wires to provide easy installation, cost savings and maximum performance in a lightweight and environmentally friendy compact package. Applications are in data critial environment such as IT, telecom and data encription but also in DC supplied industry automation.

The 5003 features a standard DC connector, offered in two different connector styles. The connector is encased with a 1-stage filter for currents up to 15 A at 125 VDC. The unit mounts to the equipment enclosure with a broad metal flange, thus providing a large contact area for optimal shielding and filter efficiency. The PCB mounting style version is available with optional snap feet to safely fasten the 5003 on the printed circuit board. The flexible wire leads allow an easy, fast and cost saving installation. Screw-on, snap-in and rivet mounting options are offered. The rear mount type with pre-threaded holes, as well as the snap-in, are designed specifically to reduce assembly time and save labor costs.

The series is ENEC and cURus approved and complies with IEC/EN 60950, standard for office and IT equipment. Applications include telecom and IT infrastructure equipment, data encryption machines but any other DC supplied equipment in industry automation.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Schurter's IEC C14 inlet with EMI filter, series 5120 ECO design, meets the increasing demands of IT, medical and industrial appliances. The existing panel mount version is now available with flexible wire leads in addition to quick connect and solder terminals. A PCB mount version is also newly introduced. The new configurations provide easy installation, cost savings and maximum performance in a lightweight and environmentally friendly compact package.

The series combines an IEC C14 or C18 inlet with line filter in various mounting styles. With the addition of the flexible wire and PCB versions SCHURTER has again expanded its range of filtered power entry modules for low and high current applications. The EMI filter is dimensioned as a 1-stage filter for rated currents up to 15 A with a leakage current standard <0.5 mA and medical <5 μA. The positive electrical contact of the broad metal flange to the chassis ensures optimal filtering and shielding.

Mounting options include screw-on, rivet or snap-in mounting. The snap-in mounting style as well as the screw-on version from rear side with its pre-formed threaded holes reduces labor costs. The PCB mount version is available with optional snap feet to safely fasten the unit on the printed circuit board. The flexible wire leads provides pre-assembly for easy and fast installation.

.

The 5120 is designed for use in IT, medical and industrial applications. The series is ENEC and cURus approved and complies with IEC/EN standards for office and medical equipment, 60950 and 60601-1 respectively.

Technical Features:
- Appliance inlet IEC C14 or C18 acc. to 60320 with EMI filter
- Current ratings: up to 10 A at 250 VAC (ENEC/UL/CSA) or 15 A at 125/250 VAC (UL/CSA)
- Screw-on or rivet mounting from front or rear side / Snap-in mounting
- PCB mounting / flexible wire connection / Quick connect terminals / Solder terminals
- Standard or medical version
- Version for enhanced withstand voltage available (X1, Y1)

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

With over 26,000 combinations Bulgin’s Polysnap mains power inlet modules offer a very adaptable and flexible solution to panel design.

Click HERE for Polysnap Catalogue

Polysnap allow combinations of mains inlets and outlets, filtered inlets, switches, fuseholders, voltage selectors, indicators and circuit breakers mounted in either horizontal or vertical format bezels ready for quick snap-fit assembly. The compact design occupies the minimum of panel area and a single rectangular mounting hole, offering easy installation for this mains power entry module.

To complement Polysnap the Polyflange range offers a flange fixing alternative for designers who prefer the security of screw fixing. All types and variations are available through Bulgin’s extensive
distribution network.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Schurter series 5008 inlet, according to IEC C8, with integrated EMI filter meets the increasing demands of IT, medical and consumer appliances for cost reduction and downsizing. The 5008 inlet provides a maximum performance and cost savings in a lightweight and environmental friendly package. The new design is now available with options for screw and snap-in mounting version.

The new 5008 series combines an IEC C8 inlet with a line filter for low power applications.  The EMI filter is dimensioned as a 1-stage filter for rated currents up to 2.5 A according IEC respectively 6 A according UL and available as standard or medical version. The integrated EMC filtering mounts directly at the point of power entry, ensuring an optimal effect on the electromacnetic compatibility performance of the unit.

Mounting options include screw-on or snap-in mounting. The snap-in mounting technique reduces the assembly costs considerably for reduced handling and ease of assembly. The connection is made with quick-connect terminals. Optional solder terminals are also available.

The unit is designed for use in IT, medical and home applications appliances. The 5008 is the optimal solution, combining uncompromised features and performance with compactness of design to meet the increasing demands in cost efficiencies and ecological concerns. The series is ENEC and cURus approved and complies with IEC/EN standards for office and medical equipment, 60950 and 60601-1 respectively.

Technical Features:
* Appliance inlet IEC C8 acc. to 60320 with EMI filter
* Current ratings: up to 2.5A at 250 VAC (ENEC/UL/CSA) or  A at 125/250 VAC (UL/CSA)
* Screw-on mounting and snap-in mounting
* Standard and medical version

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The SCHURTER 6610 is the first of its kind appliance outlet using IDC terminal technology. This novel product allows significant reduction of labour costs by supporting a more effi-cient assembly method. Multiple outlets can be banked and wire connections can be bussed, connecting the terminals all at once. The product is especially suited for power distribution units and appliances with multiple power outputs.

The IEC F appliance outlet is equipped with IDC terminals and available for two different wiring versions, “along” and “across” to the connector pin axis. The terminals accept insulated solid wires with cross section AWG12 / 2.5 mm2 and AWG16 / 1.0 – 1.5 mm2. The component is designed for snap-in mounting and comes with a protection cover. The cover aids in pressing the wires and, at the same time protects from electrical shock. Special versions with an individual quick connect or solder line terminal are available. The series has ENEC and cURus approvals and is suitable for applications in accordance with IEC/EN 60950.

Technical Features:
- Appliance outlet F according to IEC 60320 with IDC terminals
- Cross sections: AWG12 / 2.5mm2 or AWG16 / 1-1.5mm2
- Snap-in mounting for panel thicknesses 0.8 mm – 3.0 mm
- ENEC & cURus approvals for 10 A / 15 A at 250VAC (AWG 16 version not UL approved)

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The new power entry modules, types 6135 and 6136, from SCHURTER combine appliance inlet and circuit breaker into one component. The two types provide a simple and cost effective means of over current protection, particularly suited for applications with motors.

The IEC C20 appliance inlet integrates the TA35 circuit breaker from SCHURTER. The 1-pole circuit breaker is equipped with a thermal trip-free release and offers current ratings from 50 mA to 16A (ENEC) or 20A (cURus).

 The rocker is available in various colours, legends, with or without illumination. The power entry module is arranged for cost effective snap-in mounting. Typical areas of applications are to be found in laboratory equipment, medical appliances, fit-ness equipment and ergo meters, with automatic winding and coiling devices, as well as with do it yourself machines. The product is approved to ENEC and cURus.

Technical features:
- Appliance inlet C20 according to IEC 60320 with circuit breaker TA35
- 1-pole circuit breaker
- Snap-in mounting for panel thicknesses 1.5 mm – 2.5 mm
- ENEC & cURus approvals for 16 A / 20 A at 250VAC

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The latest power entry module (PEM) by Schurter, DA22, is built compact and provides maximum electrical power density.  The unit offers optimal EMC filter performance, features built-in overload protection and ensures resource-saving mounting.

The DA22 product line, specifically designed for PCB mounting, combines an IEC appliance inlet, a fuse and a filter into one unit. Pre-wired, this product requires only minimal PCB space and can be mounted with very little time required for wiring.

This new PEM integrates EMC filtering and shielding directly at the point of power entry, which has an optimal effect on electromagnetic compatibility. Overload protection is provided by a 1-pole or 2-pole fuseholder for 5x20 fuse links.

The unit is screwed onto the appliance chassis’ wall from the inside, the screw-on connection with the printed circuit board ensuring optimal mechanical safety.

DA22 is rated for currents up to 10 A at 125/250 VAC. The entire product line is ENEC and cURus approved and meets the requirements for appliances according to IEC 60950. The versions featuring Extrasafe fuseholders and medical appliance filters are ideally suited to medical appliances according to IEC 60601-1.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Bulgin Components is pleased to announce a new range of connectors designed for use in hazardous environments - the EXPlora series.

Independently tested for compliance to ATEX standards for use in Zone 2 and Zone 22 environments, the new EXP series is manufactured from a tough high grade UL94V-0 rated Polycarbonate material. Similar in construction to Bulgin’s popular 900 Series Buccaneer, the connectors are environmentally sealed to IP68 to provide protection for the most severe of dust and water borne environments. Ambient temperature range is from –20°C to +55°C.

The ATEX coding is: Ex II 3 GD and the certificated no: Baseefa 09ATEX0232X.

Compact in design, the connectors are available in 2, 3, 4, 5, 7 and 10 pole variants and in four body styles - cable, in-line cable, panel and flange fixing. Each contact insert is available with either pin or socket contacts and either can be used with any of the body styles to give the maximum choice of combinations.  They are rated up to 18A, 600Vac/dc for 2, 3, 4 and 5 poles, 16A, 430Vac/dc for 7 pole and 10A, 250Vac/dc for 10 poles. The 3, 4, 5 and 7 pole versions have leading earth contacts making them suitable for single or three phase applications.

The EXPlora series connector achieves an environmental seal to IP68 as soon as the locking ring is tightened, without any supplementary sealing. Sealing caps, with strong steel retaining cords, maintain the sealing integrity when connectors are not mated. The IP68 rating is tested submerged at 10m for two weeks.

Screw fixing terminal contacts, designed to accommodate conductors up to 4mm2, require no special tooling and allow the connector to be easily terminated and maintained ‘in the field’, while positive location keyways prohibit the possibility of mis-connection. Two designs of cable retention and alternative sealing glands allow for cable acceptance from 7mm through to 22mm diameter.

The connectors are designed for a wide variety of applications in mind, where a secure, reliable and easy to terminate interface is required, particularly for manufacturers supplying machines, equipment and systems where these explosive atmospheres might exist. As well the petrochemical industries, this could include; mills and grain stores, paint and ink manufacturers, timber mills and processors, cement works, shipyards and sewage treatment.

The EXPlora range is most suited to manufacturers of ancillary electrical equipment such as motors, pumps, lighting equipment, process and control gear for use in factories and plant where hazardous, or explosive atmospheres can be caused by flammable gases, mists or vapours or by combustible dusts.
