The new power entry modules, types 6135 and 6136, from SCHURTER combine appliance inlet and circuit breaker into one component. The two types provide a simple and cost effective means of over current protection, particularly suited for applications with motors.

The IEC C20 appliance inlet integrates the TA35 circuit breaker from SCHURTER. The 1-pole circuit breaker is equipped with a thermal trip-free release and offers current ratings from 50 mA to 16A (ENEC) or 20A (cURus).

 The rocker is available in various colours, legends, with or without illumination. The power entry module is arranged for cost effective snap-in mounting. Typical areas of applications are to be found in laboratory equipment, medical appliances, fit-ness equipment and ergo meters, with automatic winding and coiling devices, as well as with do it yourself machines. The product is approved to ENEC and cURus.

Technical features:
- Appliance inlet C20 according to IEC 60320 with circuit breaker TA35
- 1-pole circuit breaker
- Snap-in mounting for panel thicknesses 1.5 mm – 2.5 mm
- ENEC & cURus approvals for 16 A / 20 A at 250VAC

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

ASO: Quick-acting fuse up to 1000 VDC in a compact design 10.3x38
FSO: Fuseholder for standard DIN rail mount

Schurter introduces the new solar fuse ASO and fuseholder FSO with quick-acting characteristic to protect photovoltaic and similar DC-applications. The new product extend the strategic segment “renewable energy” with a 1000 VDC fuse with a current range from 1 A to 30 A and a touch safe fuseholder FSO. As PV systems have grown in sitze, so have their circuit protection requirements such as voltage rating. This high performance DC fuse is in a compact 10.3x38 mm package.

The ASO fuse protects PV modules, conductors and similar DC-applications from the potentially devastating effects of a low short circuit current in systems upwards of 1000 VDC.

The wire bonding makes the fuse stable and reliable with an operating temperature range of -40°C to 85°C. The ASO fuse is especially designet for protecting DC low short circuit current and overvoltage conditions like solar panels (strings), inverters, battery charges and combiner boxes.

The touch safe fuseholder FSO is designed for grid-tie or off-grid array combiners and standard DIN rail mount.

The products includes cURus agency approval, are RoHs compliant and halogen-free.

Technical Features:
- Current range: 1 A to 30 A
- Rated voltage: 1000 VDC
- Quick-acting characteristic according to UL 248-14
- Breaking capacity of 20 kA

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Arcolectric now offer an integral moulded guard for its 1550 and 1350 range of double pole rocker switches. The guard is an extension of the rocker switch bezel on two sides and is designed to reduce the possibility of accidental switch operation.

This option can also be used with an additional hinged cover to provide even more protection against accidental operation of the switch. The cover is available in various colours to suit the switch body colour or transparent polycarbonate for use with illuminated switches, allowing visual confirmation of switch status without having to open the protective cover.

These two new product variants are available for Arcolectric's double pole 1550 and 1350 series, on all switching operations in the L style bodies, which fit into 30mm x 22mm panel cut-outs.

This simple addition to the switch body extends the useful application of this product into areas where security or safety of switch operation is of paramount importance.

The 1500 series of switches have ratings up to 16(4)A 250Vac with a wide choice of terminal options, alternative switching circuits including 3 position types with a variety of rocker switch profiles, body sizes and bezels. The 1350 is a high in-rush version rated at 150A to EN61058-1. Matching indicators are also available to complete the range.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The new LED signal tower CleanSIGN from WERMA has been specially developed for use in food and hygiene areas as well as cleanroom applications.  Right from the start, existing standards and guidelines were given careful consideration and experts in the field of Hygienic Design were called upon for advice.

Thanks to its revolutionary design, its smooth surfaces and the materials employed, CleanSIGN meets the high requirements of “Hygienic Design”, thus making a significant contribution to the safe and clean manufacture of food and drink, cosmetics and pharmaceutical products.

Unique “Hygienic Design” Signal Tower

What Advantages Does the New CleanSIGN Offer?
* Food safety due to the absence of uneven surfaces, raised or countersunk elements where
  contamination could collect
* Cleaning-friendly and hygienic design to facilitate cleaning and disinfecting
* Use of food safe materials (FDA approval) and resistant to cleaning agents
* Maintenance-free LED technology with a long life in excess of 50,000 hours
* EHEDG and Fraunhofer IPA approved
* Fulfills Air Cleanliness Class 2 for Cleanroom applications in accordance with DIN EN ISO 14644-1
* IP 67/IP 69k protection rating
* Simple fixing and connection
* Pine Tree Clip® for quick and simple fixing
* Electronic modularity of the individual tiers
* Integrated high-output buzzer

What Benefits Do You Enjoy?
1) High safety and quality of your products
   * Prevents impurities
   * Reduces the risk of contamination

2) Reduces the cleaning workload
   * Cleaning-friendly design simplifies residue-free removal of contaminants
   * Quicker, more efficient cleaning saves energy, material and cleaning agents

3) Higher productivity
   * Reduction of equipment down-time leading to lower operating costs
   * Maintenance-free LED technology with a life in excess of 50,000 hours

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Finder has introduced a series of microprocessor-based room thermostats providing a temperature setting resolution accuracy of 0.1ºC and advanced setting options to help reduce energy usage in residential and commercial environments.

Two new slimline thermostats are offered, each in a choice of grey or white housings:  the 1T.31 provides LCD display and pushbutton temperature setting, while the 1T.41 provides LED indication and analogue dial temperature setting.

For both variants, selection of off, winter/heating and summer/cooling setting modes is very simple with either LCD display or blue/red colour coded LED indicators ensuring quick recognition of operating status.

A day/night selector enables temperatures to be set back by 3ºC to help further reduce energy consumption while maintaining a comfortable ambient environment.  In addition, a +5ºC frost protection setting in the off mode helps protect against burst pipes.

Designed to be used together if required in the same building, both digital and analogue thermostats are presented in a consistent 18mm deep, IP20 rated housing for wall mounting.  The thermostat supply voltage is provided by two AAA 1.5V batteries and the output contact is a 5A, 230VAC changeover relay.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The new KF-series features exceptionally large isolation distances and offers high AC-23A motor ratings.  It covers the range from 16A to 32A and offers disconnect capability of up to 1000V according to IEC 947.  The rotary contact system incorporated in a new type of modular contact block allows high mechanical life expectancy and precise and reliable contact making.

The innovative modular system is both simple and very safe while offering enormous flexibility.  All available modules can be combined, exchanged or added in the field, as can the very precisely working cam-operated auxiliary contacts.  The position of the various modules in relation to each other
can be defined by the user or, if preferred, preassembled in the factory.

* Coupling profile determines pre-closing function of switched 4th pole,
  i.e. contact modules per se are always the same

* Rotating contact movement (instead of classical vertical lifting) allows
  big contact gaps
  high mechanical life expectancy
  very precise movement sequence
  self-cleaning contacts
  forced opening and closing of contacts

* Compact (very shallow) design

* Up to 1000V insulation voltage according to IEC possible

* Lateral drive possible (latching module not in the centre but on left or right hand side)

* Visible contacts (windows) available on request

* Design allows a big variation of terminal markings

* Removal from DIN rail can be done without tool change (screw driver for cross-recessed screws sufficient)

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The Crydom 53 series of Panel Mounted 3Phase AC output Solid State Relays
now includes new IP20 touch safe models and 3Phase motor reversing models,
all meeting IEC emissions & transient susceptibility requirements.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, announces the addition of 36 new models to its successful 53 Series of Panel mounted AC output 3Phase SSR Contactors. The expanded Crydom 53 Series offer now includes models featuring IP20 touch safe covers with load current ratings of either 25 or 50 amps per channel at 530 VAC. Designed for harsh environments and available with either AC or DC input control voltages, the new 3Phase models also feature IEC emissions compliance to CISPR 11 Class A, and EMC immunity per IEC 61000-4-2 through -6, level 3.

The 53 Series offer from Crydom now also includes 2 new 3Phase Solid State motor reversing Relays rated at either 25 or 50 amps per channel. The reversing models include the same IP20 touch safe design, Class A emissions and level 3 noise immunity as the new 3 phase SSR contactor models. Available with 3 to 32 VDC input control, Reversing models include a safety control interlock circuit which prevents simultaneous forward and reversing commands.

All new Crydom 53 Series SSR Contactors and Motor Reversing SSRs are UL & cUL recognized, TUV approved and CE compliant to Low Voltage Directive.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

With the newly designed G20 the "Knife contacts" have been designed in a new way resulting in a switching capacity of 20 Amps at 1000V DC (DC-22A) and high short circuit withstand capability.  Finger-proof terminals according to EN 50274 and protection degree IP20 offer maximum safety.

In combination with a standard latching mechanism, the G20 complies with all regulations required for main switches according to IEC/EN 60204.  In addition the G20 is also ideal for AC-applications with high short circuit fault levels, as well as electronic circuitry with low current and voltages.

Of course the G20 can also be combined with many optional extras from the Kraus & Naimer product line.

 * Self-cleaning and vibration resistant knife contacts

* Compact design

* High DC switching capacity

* Highest contact reliability (better than any H-bridge contact system)

* High short circuit withstand capability

* Finger-proof terminals (IP20) even if jumper links are used

* Terminal extensions (accessory item) for ring type cable lugs (max. width 6mm) and quick connect lugs will be made available

* Heat resistant contact system according to standard EN 12101-3

G20 - with normal latching
G20S - with snap-action latching

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The DRA series feature 10 mm wide DIN Rail mounted Single Channel and
54 mm wide Four Channel DIN Rail mounted SSR Assemblies utilizing
proven Crydom SIP type AC or DC output SSRs mounted in DRS series sockets.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, introduces a new line of DIN Rail mounted Solid State Relay Assemblies and Sockets for Single Channel and Four Channel Applications. Mounting to standard 35 mm DIN Rail, the DRA series feature a variety of Industry Standard Crydom Single-in-Line AC and DC output SSRs in “ready to use” assemblies.

DRS Sockets, shipped in kit form, are available in 3 different input configurations including 3 to 15 VDC & 18 to 30 VDC each featuring LED input status indicators, and a 3 to 32 VDC or 90 to 280 VAC version without input status indicator. DRS1 Single Channel and DRS4 Four Channel sockets accept Industry Standard SIP type SSRs such as the Crydom CX and CMX series.

Crydom DRA and DRS Assemblies and Sockets offer the user a wide range of standard output and control ratings as well as the option for customer specific adaptations.
