Mains Filter: 3-Phase plus Neutral
• Compact design
• Single-stage filter with high EMI attenuation
• Reduced weight
• Low leakage current versions available

FMAD NEO is the name of the latest single-stage filter family for 3-phase systems with a neutral line. Especially compact with high performance, the new filter series is ideally suited for use in today's more portable industrial machines, designed to occupy less floor space in manufacturing plants. A wide temperature range extends its capabilities for use in many critical applications.

Three-phase control cabinets almost always have severe space constraints. Schurter addresses this problem with a completely new filter design, which is much more compact than older generations. The new, almost cubed, design makes optimum use of available space in the cabinet housing. Designed with the highest quality components, the filter attenuation remains very high relative to its more compact dimensions.

The new filter family is also suitable for devices with high EMC loads. Typical areas of application include converters for photovoltaic systems, battery storage units or charging stations for electric vehicles. These high-performance filters are also the first choice for modern frequency inverters for motor control.

The FMAD NEO filter series has screw terminals for safe and reliable wire terminations. A full metal flange guarantees a good earth ground connection upon screw mounting to the chassis. Six fixing holes are provided for the mounting itself, which allows both symmetrical and asymmetrical mounting.

The standard versions can be used over a wide temperature range from -40 °C to 100 °C. The filters are designed for currents from 16 A to 230 A at an ambient temperature of 50 °C. They are ENEC and cURus approved and recommended for applications up to 520 VAC. The standard versions are designed for industrial applications with leakage currents <13 mA. Special versions for leakage-critical applications of <3 mA are also available.

The completely redesigned models of the FMAD NEO family supplant SCHURTER FMAD filters. They offer at least identical performance with significantly smaller dimensions and weight, moreover the series is an ideal substitution for like competitor products.

Applications
- Industrial equipment, machines
- Motor drive applications
- Machine tools
- Energy inverters (photovoltaic, battery)
- Electro vehicle charging stations

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

With an extensive range of Push Button, Vandal Resistant, Piezo, Slide, Toggle and Rocker switches available, Bulgin & Arcolectric’s switch range is designed to meet the design requirements of a wide
variety of industry applications ranging from medical and industrial to marine and commercial electronics. Bulgin’s push button switches are available in front and rear panel mounted versions with three profile types including prominent, domed and low profile as well as rugged stainless steel anti vandal options.

Multiple switching options are available along with IP66, IP67 & IP68 sealed variants in addition to momentary and latching actuation. Illumination versions are available in dot and ring LED indication and a selection of illuminating colours, including bi-colour and tri-colour. Newer versions also feature LED illumination driven by 6V, 12V and 24V together with rear of panel sealing.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Eaton offers a full field-proven line of rockers designed for excellence in many applications. They enable you to maximize efficiency and increase machine uptime even in the most extreme environments.

1500/2500 Series rocker switches are available as Midsize Non-Illuminated and Illuminated, and Hi-Lite Rocker with High Inrush. The 1500H/2500H High Inrush option is designed to handle high inrush currents up to 100A peak inrush for 10 milliseconds. The two-color Hi-Lite Rocker with High Inrush version brightly indicates the ON position. This version spares the expense of more costly illuminated switches and is available with the high inrush option.

Options
• High Inrush
• Hi-Lite Rocker with High Inrush

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

UL Approved* Miniature SIL Reed Relay with Form B (N/C) Contacts

•  Single-in-line package
•  1.5kV Isolation Voltage across contacts
•  1.3A carry current
•  Up to 1000V switching voltage

The S1 Form B series is a miniature high voltage single-in-line reed relay for applications where space saving is a prime consideration, with normally closed contacts.

The coil pins are positioned near the centre of the relay while the contact pins are near the ends to give improved isolation between the high voltage contacts and the low voltage coil.

*Consult factory for UL ratings:
These products have been UL approved for use as per pollution degree 2 classification.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Eaton offers a full field-proven line of rockers designed for excellence in many applications. They enable you to maximize efficiency and increase machine uptime even in the most extreme environments.

The 1600/2600 series snap-in rocker and paddle switches boast worldwide approvals at up to 16A, 250 Vac. One switch can be used for both domestic and foreign markets. Ideal applications include appliances, electronic instrumentation, communications, medical equipment, office equipment and more.

1600/2600 Series rockers offer a wide circuit in standard or custom colors for illuminated and non-illuminated versions. Custom legends are available on the switch lever and bezel. The 1600H/2600H High Inrush option is designed to handle high inrush currents up to 100A peak inrush for 10 milliseconds. The Splashguard option features a unique moisture and water resistant seal, making it ideally suited for marine, RV and food processing applications.

Features
• Uniquely designed seal provides resistance to moisture and water.
• One switch can be used for both domestic and foreign markets, saving on costs and inventory.
• Oversized nylon lever with smooth, matte finish features a convenient thumb depression to ensure effortless touch control.

Options
• Custom Legends
• High Inrush
• Panel Cutout Fillers
• Splashguard
